A load bank in a generator is essential for testing and validating generator performance under various conditions. By simulating real-world loads, it ensures your generator operates reliably and efficiently. This advanced tool measures critical parameters like voltage, current, and frequency, helping to identify potential issues before they cause downtime.These 100kW, 150kW, and 200kW load banks offer a reliable and efficient solution for testing a variety of power equipment, including:
Generators
UPS systems
Battery banks
AC voltage regulators
Inverters
Switching power supplies
Automatic Operation: Simplify testing procedures with automatic control and monitoring capabilities.
Rack-mountable Design: The compact 4U/6U/8U chassis integrates seamlessly into standard network cabinets, saving valuable floor space.
Forced Air Cooling: Efficient forced air cooling ensures reliable operation even in demanding environments.
Wide Power Range: Choose from 100kW, 150kW, and 200kW models to match your specific testing requirements.
Pure Resistive Load: Simulate real-world load conditions for accurate testing of power supply performance.
Real-time Monitoring: Monitor key electrical parameters, including voltage and current, in real-time for informed decision-making.
Easy to Operate: The user-friendly interface allows for intuitive control and configuration.
Improved Efficiency and Uptime: Regular load testing with the Emax 1000 series helps identify potential issues before they cause outages, leading to improved system uptime and efficiency.
Enhanced Power Quality: By testing the performance of your power equipment under varying load conditions, you can ensure consistent and reliable power delivery to your critical systems.
Extended Equipment Lifespan: Proper load testing and maintenance practices can significantly extend the lifespan of your generators, UPS systems, and other power equipment.
Peace of Mind: Gain peace of mind knowing that your data center and communication equipment are operating at peak performance and are prepared for unexpected power fluctuations.
Name | Single phase resistive load -RL | ||
Model | IMAX3210-25k | IMAX3210-50k | IMAX3210-100k |
Rated Voltage | 1P2W，AC230V/220V/110V | ||
Resistive Power | 20kW | 40kW | 80kW |
Inductive power | 15kVar | 30kVar | 75kVar |
Rated Frequency | 50/60Hz | 50/60Hz | 50/60Hz |
Loading Mode | Step and shift loading | ||
Integrated resistance | |||
Load Stepping | The minimum resistance step size is 0.1kW/0.1kVar | ||
Main test items | Power supply detection long - term load, switching device life test | ||
Protection Alarm | Load short circuit, over current protection, over voltage protection, high temperature fault, emergency stop and other protection functions. | ||
Measurement and Control Parameter | Display voltage, current, active power, reactive power, apparent power, power factor, frequency and other basic functions. | ||
Noise | ≤70dB | ≤73dB | ≤75dB |
Air Outlet Mode | · Side wind in, side wind out
| · Wind in from the side down and out from the top
| |
Display Accuracy | 0.1V，0.1A | ||
Control Mode | Local manual control: Local button/air switch/touch screen control | ||
Remote intelligent control: RS485/CAN/ Ethernet | |||
Place of Use | Indoor | ||
Weight | 120kg | 220kg | 350kg |
Size | W600mm×D800mm×H800mm | W800mm×D800mm×H1400mm | W800mm×D800mm×H1600mm |
Name | Three-phase resistive load -RL | |||||
Model | IMAX3230-125k | IMAX3230-250k | IMAX3230-500k | IMAX3230-625k | IMAX3230-750k | IMAX3230-1000k |
Rated Voltage | 3P4W，AC220V/380V/400V/415V/440V | |||||
Resistive Power | 100kW | 200kW | 400kW | 500kW | 600kW | 800kW |
Inductive power | 75kVar | 150kVar | 300kVar | 375kVar | 450kVar | 600kVar |
Rated Frequency | 50/60Hz | |||||
Loading Mode | Step loading | |||||
Load Characteristic | Integrated resistance | |||||
Load Stepping | The minimum resistance step length is 1kW/1kVar | |||||
Main test items | Power supply detection long - term load, switching device life test | |||||
Protection Alarm | Load short circuit, over current protection, over voltage protection, high temperature fault, emergency stop and other protection functions. | |||||
Measurement and Control Parameter | Display voltage, current, active power, reactive power, apparent power, power factor, frequency and other basic functions. | |||||
Noise | ≤75dB | ≤80dB | ≤85dB | |||
Air Outlet Mode | Wind in from the side down and out from the top. | Side down ejection/side in side out | Wind in from the side down and out from the top. | |||
Display Accuracy | 0.1V，0.1A | |||||
Control Mode | Local manual control: Local button/air switch | Local manual control: through the load box 7 inch LCD touch screen. | ||||
Remote intelligent control: RS485/CAN/ Ethernet | Remote intelligent control: RS485/CAN/ Ethernet | |||||
Place of Use | Indoor | Indoor/Outdoor | ||||
Weight | 350kg | 650kg | 1100kg | 1350kg | 1650kg | 2300kg |
Size | W800mm×D800mm×H1600mm | W1000mm×D1200mm×H1600mm | W1200mm*D1400mm*1800mm |
| W1800mm×D1600mm×H2000mm | W2000mm×D1800mm×H2000mm |
